2. Main Features

LVM-070C Monitor contains the following features:
• • Compatible with various SDI signals
formats (SD/HD/3G)
- This product is compatible with various SDI
signals - SD/HD/3G(A/B)-SDI 480i, 576i, 1080i,
1080p, 1080psf
• • Compatible with various analog signals
- This product is compatible with various
analog signals such as CVBS(Composite),
S-Video and YPbPr(Component).
• • HDMI(with HDCP) Signal
- HDMI(w/ HDCP) input is available without any
other accessory.
• • Temperature Adaptive Color
- This product provides a self-adjustment
function for white balance(or color temperature)
utilizing internal sensor that measures the
temperature of the LCD panel
• • All-in-one type system
- Slim and all-in-one type monitor that supports
various video formats.
• • Wide Screen / Wide Viewing Angle/ 24bit
RGB interface Full HD panel
• • WaveForm/Vectorscope/Audio Level Meter
Function
- WaveForm & Vectorscope
- Embedded Audio Level Meter
• • Audio Out
- Internal Speaker(actives only with input
signals with Embedded Audio)
- Stereo Audio Out through phone Jack.
6 Multi Format LCD Monitor
• • Knob Control
- Easy to adjust user confi guration using the
control knob on the front of the monitor.
• • BLUE ONLY/MONO/Focus Assist/H/V Delay
Function
• • Range Error/Luma(Y') Zone Check (Color/
Zebra Type) Function
• • Internal Pattern Generator (0~100% Gray/
ColorBar+Pluge)
• • Markers & Safety Areas
- Center Marker, Safety Area Marker, Aspect
Marker, Display Size(Scan)
• • Power
- Basically, the product is powered by normal
DC source.
- The product can be battery-powered.
* DC 12V (Typical)
* When using a DC Adapter other than the one
supplied by the manufacturer, please be
advised that the adapter with DC 12V/3A ~ 6A
can be compatible with the monitor.
• • Additional features
- Camera Mounting Hole x 4, VESA Mounting
Standard, 600cd/m
Contrast, OSD user interface
2
Brightness, 800 : 1
