Menu Contents
[4] MARKER
MARKER
- This item selects the marker type when the MARKER is displayed on the screen.
- Marker may only be activated by pressing the MARKER button on the front of the monitor.
- Available marker types are OFF, 16:9, 4:3, 4:3 ON AIR, 15:9, 14:9, 13:9, 1.85:1, 2.35:1, 1.85:1 & 4:3.
Center Marker
- This item displays the CENTER MARKER on the screen.
- This function operates only after activating the MARKER function by pressing the MARKER button
on the front of the monitor.
Safety Area
- This item controls the size of the SAFETY AREA.
- Available types are 80%, 85%, 88%, 90%, 93%, 100%, EBU ACTION 16:9, EBU GRAPHIC 16:9,
EBU ACTION 14:9, EBU GRAPHIC 14:9, EBU ACTION 4:3, EBU GRAPHIC 4:3.
- This function operates only after activating the MARKER function by pressing the MARKER button
on the front of the monitor.
Fit Marker
- This item activates the FIT MARKER function.
- With FIT MARKER On the safety area is displayed relative to the marker in use. With FIT MARKER Off
the safety area is displayed relative to the incoming source.
- FIT MARKER is performed as below:
