DVI Digital Input Signal Format

DVI DIGITAL
Resolution (Source)
640 x 350 70Hz (IBM)
640 x 480 60Hz (IBM)
720 x 400 70Hz (IBM)
640 x 480 67Hz (MAC)
832 x 624 75Hz (MAC)
1152 x 870 75Hz (MAC)
640 x 480 75Hz (VESA)
640 x 480 72Hz (VESA)
800 x 600 56Hz (VESA)
800 x 600 60Hz (VESA)
800 x 600 75Hz (VESA)
800 x 600 72Hz (VESA)
1024 x 768 60Hz (VESA)
1024 x 768 70Hz (VESA)
1024 x 768 75Hz (VESA)
1152 x 864 75Hz (VESA)
1280 x 1024 60Hz (VESA)
1280 x 1024 75Hz (VESA)
Supported Video Mode
DotClock [MHz] f H (kHz)
25.175 31.469
25.175 31.469
28.322 31.469
30.240 35.000
57.284 49.726
100.00 68.681
31.500 37.500
31.500 37.861
36.000 35.156
40.000 37.879
49.500 46.875
50.000 48.077
65.000 48.363
75.000 56.476
78.750 60.023
108.00 67.500
108.00 60.000
135.00 79.976
1080/24p, 1080/25p, 1080/30p, 1080/50p, 1080/60p
f V (Hz)
70.086
59.940
70.087
66.667
74.551
75.062
75.000
72.809
56.250
60.317
75.000
72.188
60.004
70.069
75.029
75.000
60.000
75.025
480/60i, 480/60p,
576/50i, 576/50p ,
720/50p, 720/60p,
1080/50i, 1080/60i,
Sync (H/V)
P/N
N/P
N/P
N/N
N/N
N/N
N/N
N/N
N/N
P/P
P/P
P/P
N/N
N/N
P/P
P/P
P/P
P/P
