Summary of Contents for TVLogic LVM-171W

Page 1 Multi User’s Manual Multi-Format LCD Monitors LVM Series LVM-171W LVM-241W LVM-401W LVM-461W LVM-571W...
Page 2: Table Of Contents
Contents Warnings ................... 2 Features .................... 5 Name & Function of Each Part ............6 Menu Organization & Adjustment ........... 11 Menu Contents ................12 Other Functions ................21 Product Specification ..............24...
Page 3: Warnings
Warning · Always use set voltage. - AC 100 ~ 240V - DC 12V [Only LVM-171W] / DC 24V [Only LVM-241W] · All operating instructions must be read and understood before the product is operated. · These safety and operating instructions must be kept in safe place for future reference.
Page 4 d. When the product does not operate properly as described in the operating instructions. Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls not described in the instructions can cause damage, which often requires extensive adjustment work by a qualified technician.
Page 5 · The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings.
Page 6: Features
DVI/HDMI(HDCP) function built-in DVI/HDMI(HDCP) Input is available without any other accessory. Dual Link support (Option) LVM-171W (LVM-241W) can be equipped with password activated Dual Link support of 4:4:4 and 1080/60p formats. Additional Features Wide Viewing Angle, Loop Through (SDI), VESA Mounting Standard, 1000:1 contrast ratio (LVM-241W), 500cd brightness, Easy to Operate User Interface and Rack-Mountable Design.
Page 7: Name & Function Of Each Part
MENU ASPECT CHROMA/PHASE MARKER BLUE ONLY / MONO H/V DELAY <REAR> FACTORY PGM CVBS1/Y/G/S-Y CVBS2/Pb/B CVBS3/Pr/R/S-C HDMI DVI-I SDI IN-A SDI OUT-A SDI IN-B SDI OUT-B RS485 OUT AC IN RS485 IN REMOTE AUDIO IN AUDIO OUT (LVM-171W / LVM-241W)
Page 8 <FRONT> STAND BY ANALOG INPUT ENTER SDI INPUT SELECT UP / CONTRAST UNDER SCAN DOWN / BRIGHT ASPECT MENU MARKER CHROMA/PHASE H/V DELAY BLUE ONLY / MONO <REAR> RS485 OUT RS485 IN REMOTE AUDIO IN AUDIO OUT HDMI FACTORY PGM AC IN CVBS1/Y/G/S-Y SDI OUT-B...
Page 9 <FRONT> · ANALOG INPUT Used to select an ANALOG INPUT. Sub Menu for analog input menu-selection appears. · SDI INPUT SELECT Used to select SDI INPUT A or B. · UNDER SCAN Used to toggle between OVER SCAN & UNDER SCAN modes. (Also toggles between other Scan Modes down to: SD 1:1 SCAN mode.) ·...
Page 10 · DOWN/BRIGHT Used to move within the menus during OSD menu activation. It may also be used to control the BRIGHT value when the OSD Menu is inactive. · UP/CONTRAST Used to move within the menus during OSD menu activation. It may also be used to control the CONTRAST value when the OSD menu is inactive.
Page 11 Built in Audio Disembedder and Internal Speakers Stereo Audio out using phone jack. External Audio in for Stereo Speaker out · ~ AC IN Used to supply AC power; 100V~240V input range. · DC 12V/24V IN Used to supply DC power 12V(LVM-171W) or 24V(LVM-241W). Information Input VIDEO connection method Connector Composite...
Page 12: Menu Organization & Adjustment
Warning!! When using the product, make sure to connect the GND (power) first before connecting the input signal line. The unit may not operate properly if the input line is connected before the GND is connected. Menu Organization & Adjustment The product may be controlled and set system-wise through OSD displayed on the screen.
Page 13: Menu Contents
3. After selecting a sub menu, press ENTER to select an item with the UP/DOWN button. 4. Press ENTER to select the desired item. (Verified by highlighted field text turning red.) 5. Press ENTER to save the new value (verified by highlighted field returning to default black color.) 6.
Page 14 · Brightness This item controls the degree of brightness between MAX(50) and MIN (-50) range. · Contrast This item controls the contrast ratio between MAX(100) and MIN(-100). · Chroma This item controls saturation between MAX(50) and MIN(-50). · Phase This item controls PHASE value (Tone) between MAX(50) and MIN(-50). However, it is only available on COMPOSITE and S-VIDEO among ANALOG modes.
Page 15 · INTERNAL PATTERN This item generates internal white pattern. The white level can be set between 0% and 100% in 5% increments. · FAST MODE This item minimizes deinterlacing delay and improves the quality of fast moving fine detail in interlaced sources. ·...
Page 16 · COLOR TEMP This item controls COLOR TEMPERATURE and allows instant access to pre-stored color temperature settings of 5000K, 5600K, 6500K, 9300K and USER modes. In user mode, the user can define custom RGB Gain and Bias Values · GAIN RED This item controls red color.
Page 17 [3] MARKER menu · MARKER This selects the marker type when the MARKER is displayed on the screen. MARKER may only be activated by pressing the MARKER button on the front of the monitor. Available MARKER types are as follows: MODE MARKER CLASS 16:9, 4:3, 4:3 ON AIR, 15:9, 14:9, 13:9, 1.85:1, 2.35:1, 1.85:1...
Page 18 · MARKER MAT This item darkens the area of the outside of MARKER. The degrees of darkness are between OFF(0) and (7). The higher the number the darker the area outside of the Marker becomes · MARKER COLOR This item controls the color of the MARKER lines. Available colors are white, gray, black, red, green and blue.
Page 19 Menu Settable Values Classification NONE, ANALOG CHANNEL, DIGITAL A/B CHANNEL, BLUE PIN 1~6 ONLY, SD 1:1 SCAN, UNDER SCAN, ASPECT, H/V DELAY, 16:9,15:9,14:9,13:9 MARKER, 4:3, 4:3 ON AIR MARKER, 1.85:1, 2.35:1 MARKER, 1.85:1&4:3 MARKER, CENTER MARKER,SAFETY AREA 80% / 88% / 90% / 93%, TALLY RED, TALLY GREEN On the pin to be used, set the function you desire with the ENTER button and UP/DOWN button.
Page 20 · USER CONFIG SET This item saves three different user configurations, which can be recalled by simply selecting User 1, 2, or 3. · BACK LIGHT This item controls the LCD Panel’s backlight brightness. The value is selectable between MIN(0) and MAX(50). ·...
Page 21 · SOURCE ID This item toggles between Source ID modes. (MANUAL, ANC, Off) · SOURCE ID CHARACTER This item is used to set the 5 character source ID displayed when Source ID function is set to Manual. (Use Menu, Down, Up and Enter key to adjust Source ID characters.) ·...
Page 22: Other Functions
· WAVEFORM POSITION This item sets the waveform position.(R-B,C-B,L-B,L-T,C-T,R-T) · WAVEFORM SIZE This item sets the waveform size.( Large,Medium,Small) · TIME CODE ENABLE This item displays the time code. (VITC, LTC) Other Functions [1] ANALOG Mode Usage This product is capable of processing numerous input signals in ANALOG mode. The ANALOG input settings are as follows: 1.
Page 23 [2] SD 1:1 SCAN Mode Widescreen models provide not only an UNDERSCAN mode but also an SD 1:1 SCAN mode. These modes may be selected as follows: 1. Transfer to UNDERSCAN by pressing the UNDERSCAN button on the front of the monitor.
Page 24 DVI-DIG Video mode supports the following input signals. SMPTE-274M 1080i (60 / 59.94) SMPTE-296M 720p (60 / 59.94) SMPTE-125M 480i (59.94), 480p(59.94) When using DVI function, User must select Underscan button. If not using a native widescreen mode the image can be viewed in widescreen aspect by pressing the aspect button.
Page 25: Product Specification
Product Specification Below is the product specification LVM-171W LVM-241W 1 x DVI-I DVI-I(RGB) IN 3 x BNC Analog Input Input 2 x BNC SDI A/B Channel Input 1 x HDMI HDMI Input 3 x BNC Analog Output Output 2 x BNC...
Page 26 Product Specification Below is the product specification LVM-401W LVM-461W LVM-571W 1 x DVI-I DVI IN 1 x HDMI HDMI IN Input 3 x BNC Analog Input 2 x BNC SDI 2 Channel Input 1 x BNC 3 x BNC Analog Out Output 2 x BNC SDI 2 Channel Output...
Page 27 LVM - 571W LHM - 400W LHM - 460W LHM - 570W Developed by For more information please visit : www.tvlogic.co.kr Suite 914 ACE TECHNO TOWER-9, 345-30 Gasan-Dong, GuemChun-Gu, Seoul, Korea TEL : +82-2-2026-1333 FAX : +82-2-2026-1339 E-mail : support@tvlogic.co.kr...
