02 MAIN FEATURES

F-7HS Monitor contains the following features :
• Compatible with various SDI signals formats
- This product is compatible with various SDI
signals : 480i, 576i, 720p, 1080i, 1080p, 1080psf
• HDMI Signal
- This product is compatible with various HDMI
signals.
• HDMI To SDI / SDI To HDMI Conversion Output
- This product features an HDMI To SDI conversion
output so that video source from HDMI In
terminal can be output through SDI Out terminal.
- The SDI To HDMI conversion output is also
supported. The video source from SDI In terminal
can be output through HDMI Out terminal.
• Audio Out
- Stereo Audio Out through phone Jack.
• Knob Control
- Easy to adjust user configuration using the
control knob on the top of the monitor.
• Custom 3D LUT Import
- Allows the users to load their own created
3D LUT files generated by color grading tools
and apply them to the monitor.
• Integrated Camera LUT
- LUTs for every major camera manufacturers are
integrated to the LUM-095G, and they can be
applied to the live input video.
- Log-C, C-Log, S-Log1, S-Log2, S-Log3, RED
Gamma 3, RED Gamma 4
• Advanced Color Adjustment OSD
- Provides various color adjustment menus
which enable the user to monitor the video
signal in the optimal settings.
• Waveform & VectorScope
- Provides various modes: Waveform,
VectorScope, Waveform Wide, Waveform YCbCr,
Waveform RGB, Waveform & VectorScope,
Waveform YCbCr & VectorScope, Waveform Full,
VectorScope Full
6
• Audio Level Meter: 16 Channel, Direction
adjustable, Pair or Group selectable, Size
changeable(Small, Large)
• Video Range Adjustment: Limited 109%, Full
• Various Marker
• Grid Display: 3x3, 4x4, 5x5, 6x6
• Timecode Display: LTC, VITC
• ARRI Camera Status: LDS Info, Index Letter
• Various Scan: Zero Scan, Over Scan, 1:1 Scan
• User Aspect
• H Flip, V Flip, H/V Flip: Manual, Auto
• Focus Assist
• H/V Delay
• Blue/Mono Only
• Various Aspect: 16:9, 4:3, 2.35:1, 1.85:1, 15:9, 16:10
• Anamorphic: 1.3X, 1.5X, 1.8X
• Luma(Y') Zone Check
• Range Error
• Zoom: 10%, 20%, ..., 90%
• Zoom Split: Left-Top, Right-Top, Left-Bottom,
Right-Bottom, Center
• Freeze
• Internal Pattern Display
• Tally Lamp and Screen Tally
• Remote Control via RS-422(RJ-45)
• GPI Control via REMOTE port
• Firmware Update & Calibration via USB(A Type)
• Power
- Basically, the product is powered by a normal
DC source.
- The product can be battery-powered.
* DC 12V 1.8A / 34V 0.6A (Typical)
