Other Functions – Input select(LVM-172W)
ANALOG INPUT MENU
DVI INPUT MENU
SDI INPUT MENU
LVM-172W is capable of processing all input signals usable in
ANALOG mode.
1. Press [ANALOG] button on the front of the monitor and activate the
OSD menu as shown on the left.
Seledt the desired input by using the [UP]/[DOWN] button and press
the [ENTER] button to confirm.
2. Input signal resolution displays on the bottom of OSD menu.
3. Press ANALOG button again to remove the OSD menu from display.
#If no image displays after selecting the desired input mode, check
and make sure that your connection is not lose or disconnected.
LVM-172W is capable of processing DVI Digital/Analog input
signal.
1. Press [DVI] button on the front of the monitor and activate the OSD
menu as shown on the left.
Select the desired input by using the [UP]/[DOWN] button and press
the [ENTER] button to confirm.
2. Input signal resolution displays on the bottom of OSD menu.
3. Press [DVI] button again to remove the OSD menu from display.
# If no image displays after selecting the desired input mode, check
and make sure that your connection is not lose or disconnected.
LVM-172W is capable of processing two SDI input signals.
1. Press [SDI] button on the front of the monitor.
2. Input signal resolution displays on the bottom of OSD menu.
3. Press [SDI] button again to remove the OSD menu from display.
#If no image displays after selecting the desired input mode, check
and make sure that your connection is not lose or disconnected.
