Product Specification
LVM-242W
1 x DVI-I
1 x HDMI
Input 3 x BNC
2 x BNC
1 x BNC
3 x BNC
Output 2 x BNC
1 x BNC
Analog
HD-SDI
SD-SDI
Input
HDMI
Signal
DVI-Analog
DVI-Digital (Graphic)
DVI-Digital (Video)
Composite
Analog
S-Video -
Input
Component
Spec
RGB
SMPTE-274M
SDI Input
SMPTE-296M
Signal
SMPTE-260M
Formats
SMPTE-125M
ITU-R BT.656 T T
2K Format
Audio IN
Audio OUT
Size
Resolution
Dot Pitch
Color
LCD
Viewing Angle
(Typical) T T
Luminance of White
Contrast
Display Area
Power
Power Consumption (Approx.)
Operating Temperature T T
Storage Temperature T T
Accessory
Option
* Above specifications may be changed without notice
SDI A/B Selected Channel Output (Active Through-Out)
640×480/800×600/1024×768/1280×768/1280×1024/720×400
640×480/800×600/1024×768/1280×768/1280×1024/720×400/1600×1200/1920×1200/1920×1080
1080p(60/59.94/50)/1080i(60/59.94/50)/720p(60/59.94/50)/480i(59.94)/480p(59.94)/576i(50)
1080p (30 / 29.97 / 25 / 24 / 24sF / 23.98 / 23.98sF)
Embedded Audio / Analog stereo (Phone Jack)
Analog stereo (Phone Jack) / Internal Speaker(Stereo)
Carrying Case / 19" Rack Mountable Kit / ND Filter
DVI IN / VGA IN
-
Analog Input
SDI A/B Channel Input
-
Analog Loop Through Output
-
Composite / S-Video / Component / RGB -
1.485Gbps
270Mbps
-
1.0Vpp (With Sync)
1.0Vpp (Y With Sync), 0.286 Vpp (C)
1.0Vpp (Y With Sync), 0.7 Vpp (Pb,Pr)
1.0Vpp (G With Sync), 0.7 Vpp (B,R)
1080i (60 / 59.94 / 50)
720p (60 / 59.94 / 50)
1035i (60 / 59.94)
480i (59.94)
576i (50)
2048 x 1080p (24/24sF/23.98/23.98sF)
24"
1920×1200 (16:10)
0.27 mm
16.7M(true), 24bit
H : 178 degrees
V : 178 degrees
400cd (center)
1000:1
518×324 mm
AC 100 - 240V / DC 24V
112 Watts
0 °C to 35 °C ( 32 °F to 95 °F )
-20 °C to +60 °C (-4 °F to 140 °F )
AC Power Code / NDF Screw
