  • Page 1 Multi Format Broadcast LCD Monitor LVM-176W LVM-182W LVM-232W LVM-246W...

  • Page 3: Table Of Contents

    Contents 1. Caution 2. Main Features 3. Controls & Functions 4. Menu Organization & Adjustment 5. Menu Operations [1] PICTURE [2] COLOR [3] MARKER [4] GPI/UMD [5] WAVEFORM [6] AUDIO [7] DISPLAY & SET 6. Firmware Upgrage 7. Button Functions 8.

  • Page 4: Caution

    LVM-176W : DC 12/24V(MAX 6A) ● repairs. LVM-246W : DC 24V (MAX 6A) ● a. When the power cord or plug in damaged. b. When a liquid was spilled on the product or •...
  • Page 5 1. Caution • When mounting the product on a wall or • When relocating the product placed on a cart, ceiling, be sure to install the product it must be moved with the utmost care. according to the method recommended by the Sudden stops, excessive force and uneven floor manufacturer.

  • Page 6: Main Features

    - Slim and all-in-one type monitor that with DC. requires no other accessories and optimized - DC 12/24V : LVM-176W for space utilization. - DC 24V : LVM-246W Waveform/Vector Scope/Luma(Y’) zone ● Remote control function check/Audio Level Meter support ●...

  • Page 7: Controls & Functions

    3. Controls & Functions LVM-176W : FRONT APERTURE APERTURE BRIGHT BRIGHT CHROMA CHROMA CONTRAST CONTRAST VOLUME VOLUME POWER ENTER POWER ENTER ANALOG UP/DOWN ANALOG UP/DOWN SDI-A MENU SDI-A MENU SDI-B WAVEFORM SDI-B WAVEFORM DIGITAL PHASE DIGITAL PHASE SCAN BLUE ONLY/MONO SCAN BLUE ONLY/MONO ASPECT...
  • Page 8 3. Controls & Functions LVM-176W : FRONT [OPERATE] Lamp [MARKER] Button/Lamp ● ● - Indicates the status of power connection and - Used to activate/deactivate the Marker. monitor operation. - The Marker is normally displayed when you - The LED is off with power off. select Aspect ratio you want in OSD Menu.
  • Page 9 3. Controls & Functions LVM-176W : FRONT [MENU] Button/Lamp [APERTURE] Knob ● ● - Activates OSD menu. - Used to adjust the picture sharpness. The value is selectable between 0~24. - It is not available in DVI ANALOG. [DOWN] Button/Lamp ●...
  • Page 10 [RS422 IN/OUT] (RJ-45) [USB] ● ● - Controls the monitor by a protocol provided - Updates new firmware and color calibration. by TVLogic or supports TSL protocol. ~ AC IN ● [DVI-I] (DVI-I) - 100 ~ 240V AC 50/60Hz ●...
  • Page 11 3. Controls & Functions LVM-182W/232W : FRONT MENU/EXIT MENU/EXIT ENTER/UP/DOWN ENTER/UP/DOWN POWER SDI-B PHONE JACK POWER SDI-A SDI-B PHONE JACK DIGITAL SDI-A SPEAKER ANALOG DIGITAL SPEAKER INPUT SIGNAL ANALOG INDICATOR INPUT SIGNAL INDICATOR INFO. BLUE ONLY INFO. H/V DELAY BLUE ONLY MARKER H/V DELAY ASPECT...
  • Page 12 3. Controls & Functions LVM-182W/232W : FRONT [STATUS INDICATOR] Lamp [SCAN] Button/Lamp ● ● - Used to display the current input mode. - Used to change the scan mode. Press the - Input Mode button to activate through the scan modes: CVBS : COMPOSITE OVER SCAN >...
  • Page 13 [RS422 IN/OUT] (RJ-45) ● - Controls the monitor by a protocol provided [OPERATE] Lamp ● by TVLogic or supports TSL protocol. - Indicates the status of power connection and monitor operation. [DVI-I] (DVI-I) - The LED is off with power off.
  • Page 14 3. Controls & Functions LVM-246W : FRONT TALLY TALLY APERTURE BRIGHT CONTRAST SDI-B PHONE JACK SDI-A DIGITAL POWER ANALOG INPUT SIGNAL APERTURE INDICATOR BRIGHT CONTRAST SDI-B PHONE JACK SDI-A DIGITAL POWER ANALOG INPUT SIGNAL INDICATOR ENTER DOWN MENU SCAN MARKER...
  • Page 15 3. Controls & Functions LVM-246W : FRONT [STATUS INDICATOR] Lamp [F1 ~ F4] Button/Lamp ● ● - Used to display the current input mode. - Performs the function that the user set as - Input Mode hot-keys. VIDEO : COMPOSITE 1/2/3...
  • Page 16 3. Controls & Functions LVM-246W : FRONT [APERTURE] Knob [USB] ● ● - Used to adjust the picture sharpness. The - Updates new firmware and color calibration. value is selectable between 0~24. - It is not available in DVI ANALOG.
  • Page 17 [RS422 IN/OUT] (RJ-45) ~ AC IN ● ● - Controls the monitor by a protocol provided - 100 ~ 240V AC 50/60Hz by TVLogic or supports TSL protocol. DC 12V/24V IN ● [DVI-I] (DVI-I) - 24V DC ● - Signal input terminal for DVI ANALOG or DVI DIGITAL signal.

  • Page 18: Menu Organization & Adjustment

    4. Menu Organization & Adjustment [1] Menu Organization [3] Menu Adjustment Procedure The product may be controlled and set Menu control sequence follows the order ● ● system-wise through OSD displayed on below: the screen. 1. Press MENU button to bring the OSD menu on the screen.

  • Page 19: Menu Operations

    5. Menu Operations [1] PICTURE NTSC Setup ● - The item sets NTSC IRE value for 0(Zero setup) or 7.5 IRE. - It is activated in COMPOSITE 1/2/3 or S-VIDEO only NTSC signal is input. Key Lock ● - The item locks all buttons except for power, source change and menu button in front of the monitor.
  • Page 20 5. Menu Operations [1] PICTURE (DVI ANALOG) Brightness Image Position ● ● - The item controls the degree of brightness - The items moves the picture position for up/ between -100~100. down/left/right. #Brightness can be adjusted by using a control knob on the front of the monitor. Contrast ●...

  • Page 21: Color

    5. Menu Operations [2] COLOR [3] MARKER Color Temp Marker ● ● - The item controls color temperature and - The item selects the marker type when the allows instant access to preset color MARKER is displayed on the screen. temperature settings of 3200K, 5600K, 6500K, - Marker may only be activated by pressing 9300K and USER 1/2/3.
  • Page 22 5. Menu Operations [3] MARKER Fit Marker USER Marker H1 ● ● - The item activates the FIT MARKER function. - The item controls the position of the first - With FIT MARKER On the safety area is user defined horizontal marker line. displayed relative to the marker in use.

  • Page 23: Gpi/Umd

    5. Menu Operations [4] GPI / UMD Menu Classifi- Settable Values cation NONE, ANALOG CHANNEL, HDMI CHANNEL, SDI-A/B CHANNEL TALLY RED, TALLY GREEN, BLUE ONLY, UNDERSCAN, ASPECT HVDELAY, 16:9 MARKER, 15:9 MARKER, 14:9 MARKER, 13:9 MARKER, 4:3 MARKER, 4:3 ON AIR MARKER, 1.85:1 MARKER, 2.35:1 MARKER, 1.85:1 &...
  • Page 24 ● size of UMD letter box. - The item sets the ID of each monitor for the - The selectable items are [Small] and [Large]. TVLogic control protocol or DYNAMIC UMD using RS-422/485 communication. RS422 baud rate ● - The items sets the monitor control program that TVLogic provides and Baud rate.
  • Page 25 D-UMD(D-8C) is set in UMD DISPLAY. - The selectable values are DEFAULT and USER COLOR. * Default : Original TVLogic managing method (VRT) * User color : Each user can set each tally color. - When user color is selected, TALLY1 COLOR ~ TALLY4 COLOR items are activated.
  • Page 26 5. Menu Operations [4] GPI / UMD <Dynamic UMD Protocol (TSL V3.1)> * Transmission (18 Byte) (PC or Device -> Monitor) HEADER CONTROL DISPLAY DATA (1 BYTE) BYTE(1 BYTE) (16 BYTE) * [HEADER] : Display address (0~126) + 80 hex. * [CONTROL BYTE] bit 0 : Tally 1 (1=on, 0=off) bit 1 : Tally 2 (1=on, 0=off)
  • Page 27 5. Menu Operations [4] GPI / UMD Tally Type - Default ● - S-8C(Single 8 Character) & S-16C(Single 16 Character) Bit 1 Bit 1 Operation (Tally2) (Tally1) CHANNEL1 CHANNEL1 CHANNEL1 CHANNEL1 - D-8C(Dual 8 Character) Bit 1 Bit 1 Operation (Tally4) (Tally3) CHANNEL1...

  • Page 28: Waveform

    5. Menu Operations [5] WAVEFORM Waveform Intensity ● - The item controls the brightness of the WAVEFORM/VECTOR display. - Available values are between 1 ~ 63. The higher the number the brighter the waveform will be. Waveform Trans. ● - The item controls the transparency level of the WAVEFORM/VECTOR.
  • Page 29 - The range of HDMI/Analog signal may change depending on output resolution as below. * LVM-176W : Min. 0, Max. 768 LVM-182W : Min. 0, Max. 768 LVM-232W : Min. 0, Max. 1080 LVM-246W : Min. 0, Max. 1200 Multi Format LCD Monitor 29...
  • Page 30 5. Menu Operations [5] WAVEFORM C Max ● - Sets the max. value of Chroma (C’) between 0~255. - The part exceeding the set value is displayed by red in Waveform and by blinking on the screen. C Min ● - Sets the min.

  • Page 31: Audio

    5. Menu Operations [6] AUDIO Level Meter Reference ● - The item sets audio level default. - Available values are -18dB and -20dB. - Audio within selected value is displayed in green and exceeded audio level is displayed in yellow. Audio exceeding -4dB is displayed in red.

  • Page 32: Display & Set

    5. Menu Operations [7] DISPLAY & SET Key LED ● - The item turns on / off LED in front of the monitor. - Even though you turn off KEY LED, when you press LED button in front of the monitor, the LED is on and after 5 sec.
  • Page 33 5. Menu Operations [7] DISPLAY & SET TimeCode Enable ● - The item sets timecode. - Available modes are OFF, VITC and LTC. Focus Assist ● - The item makes you check which point your camera’s focus is on easily by showing a color on focused area.
  • Page 34 5. Menu Operations [7] DISPLAY & SET S/W upgrade ● - firmware-updates with USB memory stick(Thumb drive). S/W upgrade start ● - When S/W upgrade is [On], the monitor detects USB memory stick, and update is available, it is activated. 34 Multi Format LCD Monitor...
  • Page 35 * During the update, the monitor screen is off, and nothing functions. * After the update, TVLogic logo shows up on the screen, and the monitor initializes. * Update can take 10~20min. depending on firmware kind.

  • Page 36: Button Functions

    7. Button Functions [1] ANALOG LVM series monitor supports various ● analog input signals. 1. Press [ANALOG] in front of the monitor and activate OSD menu as the left photo. Select input you would like to use by Knob or UP/DOWN KEY and press the knob. 2.
  • Page 37 7. Button Functions [2] DIGITAL INPUT [3] SDI INPUT LVM series monitor supports HDMI/DVI LVM series monitor supports two HD/ ● ● digital input signal. SD/3G-SDI inputs. 1. Press [HDMI] in front of the monitor and 1. Press [SDI-A] or [SDI-B] in front of the activate OSD menu as the left photo.
  • Page 38 2 sec. and activate OSD menu as the left photo. 2. Select input you would like to use by Knob and press the knob. 3. Afterward, [F1]~[F5] perform the designated functions. <LVM-182W/232W> <LVM-246W> 38 Multi Format LCD Monitor...

  • Page 39: Other Functions

    8. Other Functions [1] SCAN The function can select various scan - 2:1 Scan : Magnifies the original image double ● and displays it only when the original image mode. size is smaller than a half of the screen size. Press [SCAN] in front of the monitor and ●...
  • Page 40 LVM-232W/246W : Min[100] ~ Max[1920] - Control range for height : LVM-176W/182W : Min[100] ~ Max[768] LVM-232W : Min[100] ~ Max[1080] LVM-246W : Min[100] ~ Max[1200] - The size-adjusted picture always stay in the center of the screen. 40 Multi Format LCD Monitor...
  • Page 41 8. Other Functions [3] WAVEFORM / VECTORSCOPE Waveform / Vector VectorScope ● ● - This function sets the Waveform and - Displays the color components ‘B-Y’ and ‘R-Y’ Vectorscope. of the input signals onto the X-Y axis. - Activates in order Off, Waveform, - Two different types of Vetorscopes are Vectorscope, Waveform wide, Waveform displayed according to SD or HD input...
  • Page 42 8. Other Functions [4] LINE SELECT [5] ZOOM (Waveform/Vectorscope) Used to select specific Vertical Line for Used to magnify the input signal from 0% ● ● WaveForm/VectorScope. to 90%. - It is available when LINE WaveForm is Supports Zoom Width Scroll / Zoom ●...
  • Page 43 8. Other Functions [6] LUMA(Y') ZONE CHECK Color Pattern Type Zebra Pattern Type ● ● - Displays the Luma(Y’) level of the input - Displays the pixels with designated Luma(Y’) image in colors. levels with zebra pattern. - Y’ ≥ 100% : Pixels with higher Y’ level than - Y’...
  • Page 44 8. Other Functions [7] FOCUS ASSIST [8] RANGE ERROR Focus Assist function assigns a color to Pixels with Y’ or C’ levels exceeding the ● ● the pixels in the shape or boundary area designated levels of Y MAX, Y MIN, C MAX of the image to inform the user to make and C MIN shall blink.
  • Page 45 8. Other Functions [9] INTERNAL PATTERN [10] INFO. (LVM-182W/232W) Displays internally generated test Displays current status and function ● ● setting of the monitor. patterns. It displays when you press [Info.] in front ● - The pattern consists of ColorBar and Pluge+ of the monitor.

  • Page 46: Dvi / Hdmi Support Resolution

    9. DVI / HDMI Support Resolution DVI ANALOG / DIGITAL /HDMI SUPPORT RESOLUTION (LVM-176W/182W) DVI-ANALOG mode supports the following modes : ● Resolution Frequency 640 X 480 60Hz, 75Hz 720 X 400 70Hz 800 X 600 60Hz, 72Hz, 75Hz 1024 X 768 60Hz, 70Hz, 75Hz 1366 X 768 60Hz / 75Hz...
  • Page 47 9. DVI / HDMI Support Resolution DVI ANALOG / DIGITAL /HDMI SUPPORT RESOLUTION (LVM-232W/246W) DVI-ANALOG mode supports the following modes : ● Resolution Frequency 640 X 480 60Hz, 75Hz 720 X 400 70Hz 800 X 600 60Hz, 72Hz, 75Hz 1024 X 768 60Hz, 70Hz, 75Hz 1366 X 768 60Hz / 75Hz...

  • Page 48: Product Specifications

    10. Product Specifications LVM-176W Size 16.84” Resolution 1366 X 768 (16:9) Pixel Pitch 0.273(H) X 0.273(V) mm Color Depth 16.7M (True 8bit) Viewing Angle H : 178 degrees / V : 178 degrees Luminance of white 350 cd/ m (Center) Contrast Ratio 900 : 1 Display Area...
  • Page 49 10. Product Specifications LVM-182W Size 18.5” Resolution 1366 X 768 (16:9) Pixel Pitch 0.300(H) X 0.300(V) mm Color Depth 16.7M (Dithered 8bit) Viewing Angle H : 178 degrees / V : 178 degrees Luminance of white 300 cd/ m (Center) Contrast Ratio 1000 : 1 Display Area...
  • Page 50 10. Product Specifications LVM-232W Size 23” Resolution 1920 X 1080 (16:9) Pixel Pitch 0.265(H) X 0.265(V) mm Color Depth 16.7M (Dithered 8bit) Viewing Angle H : 178 degrees / V : 178 degrees Luminance of white 300 cd/ m (Center) Contrast Ratio 1000 : 1 Display Area...
  • Page 51 10. Product Specifications LVM-246W Size 24.1” Resolution 1920 X 1200 (16:10) Pixel Pitch 0.270(H) X 0.270(V) mm Color Depth 16.7M (True 8bit) Viewing Angle H : 178 degrees / V : 178 degrees Luminance of white 300 cd/ m (Center)

  • Page 52: Optional Accessories

    11. Optional Accessories RACK MOUNT ANY DISPLAY UP TO 24” 8.4 inch 9 inc h 7 inch 15 inch 17 inch 21 inch 24 inch 52 Multi Format LCD Monitor...
  • Page 53 MEMO Multi Format LCD Monitor 53...
  • Page 54 MEMO 54 Multi Format LCD Monitor...
