Other Functions
WAVEFORM FEATURE (Only available in SDI mode)
WAVEFORM : Displays the shape and form of luminance level of a signal.
VectorScope: Displays color components of the input signals on the XY axis HD and SD inputs
are classified into two kinds, depending on the input. 100% and 75% scales indicated on a display.
100%
75%
