Menu Contents
[8] SYSTEM PART (1/2)
SYSTEM DEFAULT
- User can use SET DEFAULT menu to initialize the values of BRIGHT, CONTRAST, CHROMA, PHASE
and APERTURE of the monitor.
USER CONFIG SET
- This item saves three user configurations.
- Available modes are USER1, USER2 and USER3.
- Effective items are MARKER, CENTER MARKER, SAFETY AREA, MARKER MAT, MARKER COLOR,
BRIGHT, CONTRAST CHROMA, PHASE and APERTURE.
MONITOR ID
- This item sets the ID of each monitor for the TVLogic control protocol or DYNAMIC UMD using
RS-422/485 communication.
- Available values are between 0 ~ 99.
UMD DISPLAY
- This item sets UMD, ANC and DYNAMIC UMD.
* UMD : Displays user customized characters on screen.
* ANC: Displays characters embedded in SDI signal.
* DYNAMIC UMD: Displays incoming character or tally signal from TSL Protocol.
UMD CHARACTER
- This item is used to customize the characters for UMD.
- Alphabets, numbers and special symbols are available.
- Maximum of 5 characters.
UMD SIZE
- This item controls the size of UMD DISPLAY.
FIRMWARE VERSION
- This item is the firmware version of the system.
SERIAL NUMBER
- This item is the serial number of system.
