Comtech EF Data CDM-800 Installation And Operation Manual page 89

CDM-800 Gateway Router
Appendix B
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Management IPA= 18 bytes
IP Address numerical
GE1 Link LC1= 1 byte, value 0
Configuration thru 5
GE2 Link LC2= 1 byte, value 0
Configuration thru 5
Management N/A 12 bytes, alpha-
MAC Address numerical
GE1 MAC N/A 12 bytes, alpha-
Address numerical
GE2 MAC N/A 12 bytes, alpha-
Address numerical
Description of Arguments
Command or Query.
Sets the IP Address and network prefix for the 10/100 Base T Ethernet
management port, in the form aaa.bbb.ccc.ddd/yy, where:
(Permitted ranges – cannot all be zero)
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 0-255
yy = network prefix (range: 8 to 31)
Example: IPA=010.006.030.001/24
Command or Query.
GE1 Interface mode, where:
0 = Auto Negotiate
1 = 1000Mbps -Full Duplex
2 = 100Mbps – Full Duplex
3 = 100Mbps – Half Duplex
4 = 10Mbps – Full Duplex
5 = 10Mbps – Half Duplex
Command or Query.
GE2 Interface mode, where:
0 = Auto Negotiate
1 = 1000Mbps -Full Duplex
2 = 100Mbps – Full Duplex
3 = 100Mbps – Half Duplex
4 = 10Mbps – Full Duplex
5 = 10Mbps – Half Duplex
Query only.
Returns the unique MAC Address for the modem.
Example: MAC=00:06:B0:00:01:C2
Query only.
Returns the unique GE1 MAC Address.
Example: MG1=00:06:B0:00:01:C2
Query only.
Returns the unique GE2 MAC Address.
Example: MG2=00:06:B0:00:01:C2
B–7
Query
Response to
(Instruction Response to Query
Command
& Qualifier)
IPA= IPA? IPA=xxx.xxx.xxx.xxx/yy
IPA? (see Description of
IPA* Arguments)
IPA#
LC1= LC1? LC1=x
LC1? (see Description of
LC1* Arguments)
LC1#
LC2= LC2? LC2=x
LC2? (see Description of
LC2* Arguments)
LC2#
N/A MAC? MAC=aabbccddeeff
(see Description of
Arguments)
N/A MG1? MG1=aabbccddeeff
(see Description of
Arguments)
N/A MG2? MG2=aabbccddeeff
(see Description of
Arguments)
Revision 0
MN-CDM800
