Introduction
1.3.9

Supporting Hardware and Software

For future 1:1 redundant applications, the CDM-800 will be supported by the CRS-170A
Redundancy Switch for L-Band operation, or the CRS-180 Redundancy Switch for 70/140 MHz
operation. M:N redundancy support will also be available in future releases.
1.4

Summary of Specifications

Specification
Front Panel
Data Interfaces
Dimensional Envelope
Operating
Temperature
Storage
Humidity
Tx Operating Frequency
Tx Connectors & Impedance
AC
Power supply
DC (HW Option) 48 VDC
Transmit Power
BUC Reference
Supported Protocols
Data Rate
Symbol Rate
FEC
Modulation and Code Rates
Description
7 Light-emitting Diodes (LEDs):
• UNIT STATUS (Green/Orange/Red)
• STORED EVENT (Amber)
• ONLINE (Green)
• TEST MODE (Amber)
• (2X) 10/100/1000 BaseT Gigabit Ethernet (traffic)
• (1X) 10/100 BaseT Fast Ethernet (management and control)
• EIA-232 interface for router serial remote control
19.0 W x 18.15 D x 1 RU (1.7) H inches (483 W x 461 D x 44 H mm)
32° to 122°F (0° to 50°C)
-4° to 158°F (–20° to 70°C)
95% maximum, non-condensing
• 950 – 2150 MHz
• 50 – 180 MHz
• Type-N Female, 50Ω
• BNC Female, 62Ω
100-240 VAC, 47 Hz-63 Hz
• -5 to -40 dBm (950 – 2150 MHz)
• -5 to -25 dBm (50 – 180 MHz)
10.0 MHz ± 0.06 ppm, selectable ON/OFF, 0.0 dBm ± 3 dB
• RFC 768 – UDP • RFC 959 – FTP
• RFC 791 – IP • RFC 1112 – IP Multicast
• RFC 792 – ICMP • RFC 1213 – SNMP MIB II
• RFC 793 – TCP • RFC 1812 – IPv4 Routers
• RFC 826 – ARP • RFC 2045 – MIME
• RFC 856 – Telnet • RFC 2474 – Diffserv
• RFC 862 – Ping • RFC 2475 – Diffserv
• RFC 894 – IP • RFC 2578 – SMI
1 – 168 Mbps
• 1 – 62 Msps (QPSK, 8-PSK)
• 1 – 47 Msps (16-APSK)
• 1 – 37 Msps (32-APSK)
DVB-S2
• QPSK 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
• 8-PSK 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
• 16-APSK 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
• 32-APSK 3/4, 4/5, 5/6, 8/9, 9/10
1–8
• TRANSMITTER ON (Green)
• Tx TRAFFIC (Green)
• LINK/ACTIVITY (Green)
• RFC 2597 – AF PHB
• RFC 2598 – Expedite Forwarding
• RFC 2616 – HTTP
• RFC 3412 – SNMP
• RFC 3416 – SNMPv2
• RFC 3418 – SNMP MIB
