CDM-800 Gateway Router
Ethernet Management
5.4.4.4.3 Configuration | ARP
The 'Configuration | ARP' page (Figure 5-11) is used to configure the router's ARP (Address
Resolution Protocol) parameters.
Add Static ARP
This section allows the user to directly add a static ARP entry. Note that the index will
automatically increment to the next available number.
Click [Add Entry] once all changes have been made in this section.
Delete Static ARP
Enter Entry Index to Delete, then click [Delete Entry] once all changes have been made in this
section.
Flush Dynamic ARPs
Click [Flush ARP Table] to delete all dynamically learned ARP entries.
ARP Table (Edit)
This section displays all current Static and Dynamic ARP entries, and allows to user to directly
edit the current Static ARP entries. Note the following:
Index (read-only) – This is the internal table index and it cannot be edited.

Figure 5-11. Configuration | ARP page

5–16
Revision 0
MN-CDM800
