CDM-800 Gateway Router
Ethernet Management
Route Table (Edit)
This section displays and allows the user to edit all current Route Table entries. Note that the
optional Header Compression and Payload Compression features are
this time and are therefore non-functional on this page. Otherwise, note the following:
Index – This is the internal table index that is automatically assigned and cannot be edited.
Desc. – Enter a string label in this text box. Provided to help users maintain their network, the
assigned name cannot contain any whitespace and must be unique.
Dest. IP/Mask – Enter a Destination IP Address/Mask in the form XXX.XXX.XXX.XXX/YY.
Interf. – Use the drop-down menu to select the Interface as toWAN or toLAN.
WAN Label – This allows traffic to a defined remote desination to be passed. The valid label
range is from 1 to 2047.
IMPORTANT
Next Hop IP – Enter the desired Next Hop IP Address for toLAN routes (note that no Next
Hop entry is needed for toWAN routes).
Click [Submit Changes] once all changes have been made to this section.
If the WAN Label does not match any of the WAN Labels defined in the CDM-840
Remote Router, then the packets will be dropped by the CDM-840.
5–18
Revision 0
MN-CDM800
