CDM-800 Gateway Router
Ethernet Management
The user defines two Community Strings for SNMP access:
Read Community
Write Community
5.4

Web Server (HTTP) Interface

The sections that follow describe the functionality of the CDM-800 Gateway Router Web
Server (HTTP) Interface. Please refer to the Remote Commands Specifications tables found in
Appendix B. REMOTE CONTROL for detailed descriptions of the configuration parameters
featured on the individual Web pages shown in this chapter.

5.4.1 Web Server Introduction

The embedded Web Server application provides the user
with an easy to use interface to configure and monitor all
aspects of the CDM-800. These Web pages have been
designed for optimal performance when using Microsoft's
Internet Explorer Version 7.0 or higher (the examples shown
use Internet Explorer Version 7.0).
The user can fully control and monitor base operations of the CDM-800 from the Web Server
Interface. By rolling the cursor over the navigation tabs located at the top of each page (right), the
user can select from the available nested tabs.

5.4.2 User Login

To initiate a Web session with the CDM-800 Gateway Router, from the PC type
http://www.xxx.yyy.zzzz (where "www.xxx.yyy.zzz" represents the Management IP Address of the
CDM-800 Gateway Router) into the Address area of the Web browser:
The user is then prompted to type in a valid User name and Password,
similar to the dialog box shown to the right. The default for both is
comtech. Type the User name and Password, then click [OK].
Once the valid User Name and Password is accepted, the
user will see the CDM-800 Gateway Router Web Server
Interface "splash" page (right).
default = public
default = private
5–3
Revision 0
MN-CDM800
