CDM-840 Remote Router
Ethernet Management
The user defines two Community Strings for SNMP access:
•
Read Community
•
Write Community
5.4

Web Server (HTTP) Interface

The sections that follow describe the functionality of the CDM-840 Remote Router Web Server
(HTTP) Interface. Please refer to the Remote Commands Specifications tables found in
Appendix B. REMOTE CONTROL for detailed descriptions of the configuration parameters
featured on the individual Web pages shown in this chapter.

5.4.1 Web Server Interface Introduction

The embedded Web application provides the user with an
easy to use interface to configure and monitor all aspects of
the CDM-840. These Web pages have been designed for
optimal performance when using Microsoft's Internet
Explorer Version 7.0 or higher (the examples shown use
Internet Explorer Version 7.0).
The user can fully control and monitor base operations of the CDM-840 from the Web Server
Interface. By rolling the cursor over the navigation tabs located at the top of each page (right), the
user can select from the available nested tabs.

5.4.2 User Login

To initiate a Web session with the CDM-840 Remote Router, from the PC type
http://www.xxx.yyy.zzzz (where "www.xxx.yyy.zzz" represents the IP address of the CDM-840
Remote Router) into the Address area of the Web browser:
The login page will then open. To proceed
further, the user must first provide a User
Name and Password – the default for both
is comtech – then click [Log On].
default = public
default = private
5–3
Revision 0
MN-CDM840
