Appendix C – Audio Connectors and Pinouts
XLR 3-Pin
Pinout for balanced analogue audio (Mini LS):
Pin 1 -
Pin 2 -
Pin 3 -
Pinout for balanced digital audio (AES3):
Pin 1 -
Pin 2 -
Pin 3 -
D-Type Multipin
25-way
Dimensions:
Cable Dia:
9-way
Dimensions:
Cable Dia:
1/4" Jack
Pinout for headphone:
Tip Right channel
Ring Left channel
Sleeve Ground
Pinout for footswitch:
Tip Control input (connect to 0V to activate)
Ring n/c
Sleeve 0V
Screen/Ground
Hot (+ve)
Cold (-ve)
Screen
Hot (+ve)
Cold (-ve)
55 x 15mm (approx.)
8mm (typical)
35 x 15mm (approx.)
7mm (typical)
Free Plug Free Socket
1 1
2
3
Connectors Viewed From Wiring Side
13 12 11 1 9 8 7 6 5 4
25 24 23 22 21 2 19 18 17 16
1 2 3 4 5 6 7 8 9 1
14 15 16 17 18 19 2 21 22 23 24 25
5 4 3 2 1
9 8 7 6
1 2 3 4 5
6 7 8 9
Stereo
Plug
Tip(T) Ring(R) Sleeve(S)
Matrix 2
Appendix C - Pinouts
Connectors Viewed
2
From Wiring Side
3
3 2 1
Plug
15 14
11 12 13
Socket
Plug
Socket
