imagistics cm4530 Network Administrator's Manual page 175

Add Drivers to the NDPS Broker
Create a Printer Agent
Network Administrator's Guide — Setting up NetWare Print Server
4.
Add drivers to the NDPS Broker. They can then be selected
from the drivers list and associated with the Printer Agent.
1.
Launch NWAdmin.
2.
Double-click the Broker icon.
3.
Click [Resource Management (RMS)].
4.
Click [Add Resources].
5.
Select the applicable system: the Windows 98/Me/2000, Win-
dows NT or Windows XP operating system. Click [Add].
6.
Click [Browse] to locate the driver's .inf file on either the dis-
tribution CD-ROM or a shared network location.
7.
Click [OK].
Now, when you create a Printer Agent, you can associate the drivers by selecting
them from the list of drivers managed by the broker.
1.
Right-click anywhere within the Parent Level (Tree or Context
under which the NDPS Printer Agent is to be installed) and
then choose [Create].
• The New Object dialog box appears.
2.
From the "Class of New Object" list box, select "NDPS
Printer" and click [OK].
• The Create NDPS Printer dialog box appears.
3.
Enter the NDPS Printer Name, then click [Create].
• The Create Printer Agent dialog box appears.
4.
Enter the NDPS Manager name or click [Browse] to locate it.
5.
Select "Imagistics NDPS Gateway Configuration" in the
"Gateway types" list, then click [OK].
• The Gateway Configuration dialog box appears.
6.
Select the NDPS Gateway Printing Mechanism and click
[Next].
The configuration dialog that appears depends on the printing mechanism you
choose. A description of the configuration settings for each option follows. When
you finish configuring the Printer Agent, proceed to "Select Drivers" on page 176.
P.176 "LPR on IP"
P.176 "Remote Printer on IPX"
P.176 "Queue-Based (NDS Printer Agent)"
175
