imagistics cm4530 Network Administrator's Manual page 172

Configuring the queue based connection in the IPX/SPX network
172
1.
In the Configure Port Handler for Printer Agent dialog box,
select "Forward Jobs to a Queue" and click [Next].
2.
Enter the NDS queue name in the "Queue Name" field and the
user name in the "Queue User Name" field. Then click [Fin-
ish].
• The Select Printer Drivers dialog box appears.
3.
Select the printer drivers to be installed in the "Printer Driv-
ers" list at each OS tab, and click [Continue].
• The Information dialog box appears.
4.
Click [OK].
• It takes about 60 seconds to complete the creation of the NDPS
Printer object.
5.
Double-click the NDPS Printer object that you created.
• The NDPS Printer dialog box appears.
6.
Click [NDPS Remote Printer Management].
7.
Check the "Install to workstation in this container" and click
[Update].
8.
Click [OK] to close the NDPS Printer dialog box.
Network Administrator's Guide — Setting up NetWare Print Server
