6. TROUBLESHOOTING PROCEDURES

If the scanner seems to be operating abnormally, perform the troubleshooting procedures
described in this chapter before requesting a service call.

6.1 The Scanner Is Turned On But Doesn't Operate at All

Cause
The power cord has come loose.
The scanner is connected to an electrical
socket that does not provide the rated
supply voltage.
The electrical socket is not supplying
a supply voltage.
6.2 The Scanner Operates Improperly After Connection to the
Computer
Cause
The SCSI cable is not properly connected
to the computer and/or the scanner.
The SCSI adapter used is not compatible
with high-speed data transfer (SCSI-3 or
higher).
The SCSI cable connecting the computer
to the scanner is faulty.
The SCSI terminator has not been
activated.
The SCSI-ID number is incorrectly set.
The SCSI cable's overall length exceeds
3 meters.
The factory-preset default of the SCSI-ID setting is 2.
CS1000EV/1100EV
6. TROUBLESHOOTING PROCEDURES
Remedy
Firmly connect both plugs of the power cord.
Use only the rated supply voltage.
Check the power supply.
Remedy
Firmly insert the cable's connectors until they
lock into place.
Change the SCSI transfer rate (Maximum Sync
Transfer Rate) to 10 MB/s. For details, refer to
the SCSI adapter instruction manual.
Confirm that there is no fault with SCSI cable
connectors (broken or bent pins).
Fully insert the SCSI cable until it locks.
If the scanner will serve as a terminal within the
network configuration, set Bit 4 of the scanner's
DIP switch to enable the internal terminator
function.
Set the scanner's ID number to one that is different
from other devices in the network (see Section 3.4,
"Setting the ID Number").
Use a SCSI cable that is no longer than
3 meters.
6 – 1
