5. DAILY MAINTENANCE

5.3 Cleaning the Document Hold-Down Unit

Scanning may be affected if the underside of the document hold-down unit becomes
scratched or dirty. It must be cleaned when necessary.
(1) Turn off the scanner.
(2) Remove the document hold-down unit as described in Section 4.5, "Removing the
Document Hold-Down Unit."
(3) Wipe clean the underside of the document hold-down unit (see below) using a soft
cloth that has been soaked in water or diluted neutral detergent and thoroughly wrung
out.
Underside
(4) Wipe the document hold-down unit once again using a soft, dry cloth (remove all
moisture).
(5) Reattach the document hold-down unit as described in Section 4.6, "Attaching the
Document Hold-Down Unit."
5 – 4 CS1000EV/1100EV
