2. PREPARATION

2.3 Attaching the Document Support Wires

With the CS1000EV, the document support wires should be attached when using the carrier
sheet or when heavy documents are scanned.
CS1000EV
With the CS1100EV, always attach the document support wires, regardless of the type of
document being scanned.
CS1100EV
If you are using the CS1100EV model, make sure that the document support wires
are attached before beginning a scanning operation. If you perform scanning without
the wires attached, the document may be damaged if it comes into contact with the
SCSI cable.
Attaching the document support wires
(1) Insert one end of the document support wire provided into the slot at the rear of the
scanner.
2 – 6
Document support wires
Document support wires
CS1000EV/1100EV
