4.1.3

Chipset

4.1.3.1 North Bridge Configuration
DRAM Frequency
Specify DRAM frequency. You can specify whether let BIOS set
DRAM frequency automatically or configure it manually (400
MHz or 533 MHz).
Configure DRAM Timing by SPD
Specify Enable to allow the timing setting of DRAM to be con-
figured from SPD or Disable to configure it manually.
Initiate Graphic Adapter
Select which graphics controller to use as the primary boot dis-
play device. Support IGD, PCI/IGD.
Internal Graphics Mode Select
Specify the size of system memory used by internal graphics
device. 8MB is recommended.
