Matrix MXC-4000 Series
User's Manual
2.2.1

Power Button

The power button is a non-latched push button with a blue LED
indicator. The system is turned on when button is pressed, and the
power LED is also illuminated. To shut down the system, you can
issue shutdown command via the operating system or just press
the power button. If the system halts, you can also press the but-
ton for 5 seconds to force system shutdown.
2.2.2

LED Indicators

There are three LED indicators on the front panel. The following
table describes the color and function of the LED indicators.
LED indicator
Watchdog (WD)
Hard disk drive (HD)
Power LED (PW)
2.2.3

Reset Button

The reset button is used to perform a hard reset of the MXC-
4002D/4011D controller.
12
Color
Yellow
Indicates the status of watchdog timer.
When the watchdog timer is started, the
LED is flashing. And when the timer is
expired, the LED is on.
Orange Indicates tthe operating state of HDD.
When the SATA hard drive or internal CF
card is active, the LED indicator is flash-
ing.
Green
Indicates the status of the power.
When the power is presed, the LED will
be on.

Table 2-2: LED Indicators

Description
System Description
