DVMT Mode Select
Dynamic Video Management Technology (DVMT) allows addi-
tional system memory to be dynamically allocated in operating
system for graphics usage. Once the application is closed, the
allocated memory is released and is then available for system
usage. DVMT ensures a solid balance between system perfor-
mance and graphics performance.
Option
Fixed Mode
DVMT Mode
Boot Display Device
Select system boot display device, options are VGA or
VGA+LVDS. The default option is VGA+LVDS.
Flat Panel Type
Select the display resolution of flat panel, supported options
are "800X600" and "1024X768".
52
The graphics driver reserves a fixed portion of the
system memory as graphics memory.
The graphics driver dynamically allocates system
memory for graphics usage, according to system and
application demands.

Table 4-3: DVMT Mode Select

Description
BIOS Settings and Driver Installation
