Matrix MXC-4000 Series
User's Manual

2.4 Gigabit Ethernet (WG82574L)

The MXC-4002D/4011D controller has two GbE ports on the front
panel by Intel WG82574L Gigabit Ethernet controller.
The Ethernet controller supports the following features:
x1 PCI Express® interface with 2.5 GHz signaling
PCIe* advanced extensions
Message signaled interrupts
TCP Segmentation/Transmit Segmentation Offloading
(TSO) support
IEEE 802.3x and 802.3z compliant flow control support
IEEE 802.1q support
Compliant with 1 Gb/s Ethernet IEEE 802.3x PHY specifica-
tions
Automatic MDI/MDIX crossover at all speeds
ACPI 2.0 specification
Full wake-up support
Fully integrated ASF 2.0 functionality with on-chip μc
SMBus 2.0 master interface for ASF functionality
Preboot eXecution Environment (PXE) flash interface sup-
port
18
System Description
