Matrix MXC-4000 Series
User's Manual

2.5 Internal I/O Connectors

The section describes the internal I/O connectors of the MXC-
4000 series. MXC-4002D and MXC- 4011D have the same inter-
nal I/O connectors. The figure showed below is what's inside the
MXC-4000 series.
26
B
A
This page intentionally left blank.
Symbol
A
CompactFlash Socket
B
FAN connector
C
SATA connector
D
Clear CMOS button

Table 2-11: Internal I/O Connectors

Function
D
C
System Description
