SDS2100 User Guide

Monitor Mode

Monitor Mode is a command-line interface used for diagnostic purposes (see
Mode Commands
Mode: locally via the serial port or remotely via the network.

Via the Serial Port

To enter Monitor Mode locally, follow the same principles used in setting the serial
configuration parameters:
1. To enter Monitor Mode with network connections, type xx1 or zzz (not three x
keys as you did before).
OR
2. To enter Monitor Mode without network connections, type xx2 or yyy.
A 0> prompt indicates that you have successfully entered Monitor Mode.

Via the Network

To enter Monitor Mode using a Telnet connection:
1. First establish a Telnet session. The following message displays:
2. Type M (upper case).
A 0> prompt indicates that you have successfully entered Monitor Mode.

Monitor Mode Commands

The following commands are available in Monitor Mode. Many commands have an IP
address as an optional parameter (x.x.x.x). If the IP address is given, the command is
applied to another unit with that IP address. If no IP address is given, the command is
executed locally.
Note: All commands must be given in capital letters, with blank spaces
between the parameters.
at the end of this section). There are two ways to enter Monitor
Figure 5-1. Entering Monitor Mode Via the Network
*** Lantronix Secure Device Server ***
MAC address 00204A0250AF
Software Version 05.6b3 <040311> SDS2100
AES library version 1.8.2.1
Press Enter to go into Setup Mode
_
55
5.Troubleshooting
Monitor
