SDS2100 User Guide
Command Command Name
SF x.x.x.x Send Firmware
VS x.x.x.x Version
GC x.x.x.x Get Configuration
SC x.x.x.x Send Configuration
PI x.x.x.x Ping
AT ARP Table
TT TCP Connection Table
NC Network Connection
RS Reset
SI
Send/Set IP Address
x.x.x.x:n.n.n.n
QU Quit
G0, G1...GE, Get configuration from
GF memory page
S0, S1... SE, Set configuration to
SF memory page
Entering any of the commands listed above will generate one of the following
command response codes:
Table 5-2. Monitor Mode Commands
Function
Sends firmware to unit with IP address x.x.x.x
Queries software header record (16-byte) of unit with IP address
x.x.x.x
Gets configuration of unit with IP address x.x.x.x as hex records
Sets configuration of unit with IP address x.x.x.x from hex records
Pings unit with IP address x.x.x.x to check device status
Shows the unit 's ARP table entries
Shows all incoming and outgoing TCP connections
Shows the unit 's IP configuration
Resets the unit 's power
Remotely assigns an IP address to a unit, where x.x.x.x is the new IP
address and n.n.n.n is the remote unit's serial number written twice
Exits diagnostics mode
Gets a memory page of configuration information from the device.
Sets a memory page of configuration information on the device.
Table 5-3. Command Response Codes
Response Meaning
0> OK; no error
1> No answer from remote device
2> Cannot reach remote device or no answer
8> Wrong parameter(s)
9> Invalid command
56
5.Troubleshooting
