SDS2100 User Guide
The unit performs a power reset after the firmware has been loaded and stored.
Via Another Unit
To distribute firmware to another unit over the network:
1. Enter the host unit's Monitor Mode (see
chapter).
2. Send the firmware to the receiving unit using the SF command, where x.x.x.x is
the receiving unit's IP address.
The receiving unit performs a power reset after the firmware has been loaded and
stored.
Note:
You can only update your unit 's internal Web interface using TFTP or
DeviceInstaller.
Figure 4-5. TFTP Dialog Box
C:\SDSxxxx.ROM
D2
172.19.23.55
Figure 4-6. Sending Firmware to Another Unit
SF x.x.x.x
48
4. Updating Firmware
Monitor Mode
in the Troubleshooting
