4: Updating Firmware; Obtaining Firmware; Reloading Firmware; Via Deviceinstaller - Lantronix SecureBox SDS2100 User Manual

4 : U p d a t i n g
4 : U p d a t i n g

Obtaining Firmware

You can obtain the most up-to-date firmware and release notes for the unit from the
Lantronix Web site (http://www.lantronix.com/) or by using anonymous FTP
(ftp://ftp.lantronix.com/).

Reloading Firmware

There are several ways to update the unit's internal operational code (SDS*.ROM or
SD21*.HEX): via DeviceInstaller (the preferred way), via TFTP, via another unit, or
via serial port. You can also update the unit's internal Web interface (CBXW*.COB)
via TFTP or DeviceInstaller.

Via DeviceInstaller

After downloading the firmware to your computer, you can use DeviceInstaller to
install it. If you haven't already installed DeviceInstaller from the product CD, see
Install the
1. Download the updated firmware files from
ftp://ftp.lantronix.com/
2. Click the Start button on the Task Bar and select Programs
DeviceInstaller
F i r m w a r e
F i r m w a r e
DeviceInstaller.
and store them in a subfolder on your computer.
Device Installer. The DeviceInstaller window displays.
Figure 4-1. DeviceInstaller Window
45
www.lantronix.com or
Lantronix
