SDS2100 User Guide
Technical Specifications
CPU, Memory
Serial Interface
Network Interface
Power Supply
Power Input
Dimensions
SDS2100
Weight SDS2100
Temperature
Relative Humidity
Lantronix DSTni-LX 186 CPU, 48 MHz
1 MByte FLASH ROM
256 Kbytes zero wait state RAM
2 Male DB9 Connectors (DTE pinout)
Speed software selectable (300 to 115 kBaud)
RS-232C
10/100 RJ45 Ethernet
External adapter included
120VAC USA
100 - 240 VAC Universal with regional connectors
9-30 VDC or 9-24 VAC (2W maximum)
Height: 2.3 cm (0.9 in)
Width: 7.3 cm (2.87 in)
Depth: 9.5 cm (3.74 in)
0.35 Kg (0.8 lbs)
Operating range: 5° to 50° C (41° to 122° F)
Storage range: -40° to 66° C (-40° to 151° F)
Operating: 10% to 90% non-condensing, 40% to 60% recommended
Storage: 10% to 90% non-condensing
13
1: Introduction
