SDS2100 User Guide

Network Port

The unit's back panel contains a 9-30VDC power plug and an RJ45 (10/100)
Ethernet port.

Ethernet Connector Pinouts

LEDs

The SDS2100 contains the following LEDs:
Simultaneously lit red and green LEDs mean something is wrong. If the red LED is lit
or blinking, count the number of times the green LED blinks between its pauses. The
following table explains the LED functions:
Figure 1-3. Network Interface
RJ45 Ethernet Port
Figure 1-4. RJ45 Ethernet Connector
Power
10 Mbps Link/Activity (green)
100 Mbps Link/Activity (green)
Diagnostics (red)
Status Channel 1 (green)
Status Channel 2 (green)
Power Plug
11
1: Introduction
