SDS2100 User Guide

Serial Port Login

If you want to initially configure the unit through a serial connection, follow these
steps:
1. Connect a console terminal or PC running a terminal emulation program to the
unit's Channel 1 serial port. The default serial port settings are 9600 baud, 8 bits,
no parity, 1 stop bit, no flow control.
2. To enter Setup Mode, cycle the unit's power (power off and back on). After
power-up, the self-test begins and the red Diagnostic LED starts blinking. You
have one second to enter three lowercase x characters.
Note:
the terminal (or emulation) while powering up the unit.
3. Select 0 (Server Configuration) and follow the prompts until you get to IP
address.
4. Enter the new IP address, Subnet Mask, and Gateway (if applicable).
5. Select 9 to save the configuration and exit Setup Mode. The unit performs a
power reset.
The easiest way to enter Setup Mode is to hold down the x key at
23
2: Getting Started
