Lantronix SecureBox SDS2100 User Manual page 26

SDS2100 User Guide
To configure the unit via a Web browser, select SDS Settings and perform the
following steps.
1. Use the menu (pushbuttons) to navigate to sub pages where you can configure
server settings. See explanations of the configuration parameters later in this
chapter.
Note:
in this chapter correspond to the Setup Mode window rather than to the
WEB-Manager sub pages.
2. When you are finished, click the Update Settings button to save your settings.
For example, to enter server properties:
1. Click the Server Properties button. The Server Properties section of the Web
page displays.
2. Confirm or enter values for:
Figure 3-3. Lantronix WEB-Manager
The sequence of parameters explained and examples shown later
IP Address
Subnet Mask
Gateway Address
26
3: Configuring the Unit
