SDS2100 User Guide
Note: If you do not want to convert the binary numbers to hexadecimals
yourself, look up the values in
Binary to Hexadecimal chapter.
Connect Mode Option
Incoming Connection
Never accept incoming
Accept incoming with DSR
Accept unconditional
Response
Nothing (quiet)
Character response (C=conn, D=disconn, N=unreachable)
Startup
No active startup
With any character
With active DSR
With CR (0x0D) only
Manual connection
Autostart
Hostlist
Datagram Type
Directed UDP
Modem Mode
Full Verbose
Without Echo
Numeric modem result codes
Manual Connection: When you use manual connection, you are not required to
enter the entire IP address if the IP is already configured as the remote IP address in
the unit. For example, if the remote IP address already configured in the unit is
129.1.2.3, then an example command string would be C3/7. (This would connect to
129.1.2.3 and port 7.) You may also use a different ending for the connection string.
For example, C50.1/23 would connect you to 129.1.50.1 and port 23.
Command String Result if remote IP is 129.1.2.3 and remote port is 1234
C121.2.4.5/1
C5
C28.10/12
Autostart (Automatic Connection): If autostart is enabled, the unit automatically
connects to the remote IP address and remote port specified.
Datagram Type: When selecting this option, you will be prompted for the Datagram
type. Enter 01 for directed or broadcast UDP.
Table 6-2. Connect Mode Options
Table 3-6. Connect Mode Options
Table 3-7. Manual Connection Address Example
Complete override; connection is started with host 121.2.4.5,
port 1
Connect to 129.1.2.5, port 1234
Connect to 129.1.28.10, port 12
34
3: Configuring the Unit
in the
Bit 7 6 5 4 3 2 1 0
0 0 0
0 1 0
1 1 0
0
1
0 0 0 0
0 0 0 1
0 0 1 0
0 0 1 1
0 1 0 0
0 1 0 1
0 0 1 0
1 1 0 0
1 0 1 1 0
0 0 1 1 0
1 0 1 1 1
