Icom IC-7700 Instruction Manual page 103

D D Filter shape set mode (continued)
HF SSB (600Hz – )
Select the filter shape for SSB mode in HF bands.
SSB–D (600Hz – )
Select the filter shape for SSB data mode in HF
bands.
CW ( – 500Hz)
Select the filter shape for CW mode in HF bands.
CW (600Hz – )
Select the filter shape for CW mode in HF bands.
50M SSB (600Hz – )
Select the filter shape for SSB mode in 50 MHz band.
SSB–D (600Hz – )
Select the filter shape for SSB data mode in 50 MHz
band.
CW ( – 500Hz)
Select the filter shape for CW mode in 50 MHz band.
CW (600Hz – )
Select the filter shape for CW mode in 50 MHz band.
FUNCTIONS FOR RECEIVE
SHARP
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SHARP
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SHARP
The set filter shape is automatically used only
when the IF filter is set to 500 Hz or narrower.
SHARP
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SOFT
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SHARP
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SHARP
The set filter shape is automatically used only
when the IF filter is set to 500 Hz or narrower.
SHARP
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
5-15
5
