Introduction

External Locator - Top View with LCD Panel Open

Figure 1
Top View
1. PC Camera
2. PC Camera LED
3. Built-In
Microphone
4. LCD
5. Power Button
6. Keyboard
7. Touchpad &
Buttons
1 - 4 External Locator - Top View with LCD Panel Open
2 3
1
4
5
6
7
