Figure 1-6
Rear Panel View with AC Power and Communication Cables

First-time Power-up

1
2
•
•
3
Polycom, Inc.
For the RTM ISDN 1500 module:
— Connect the E1/T1 cables to their PRI (1-4) ports.
E1/T1 PRI
Power Cable
Connection(s)
RMX 1500
For first entry installation, you must insert the USB key containing the modified IP
addresses in USB slot on the RMX's front panel. For more information see, the
RealPresence® Collaboration Server 1500/2000/4000 Getting Started Guide, "Procedure 1:
First-time Power-up" on page 2-27.
Turn ON the power by pressing on the power switch located on the front panel of the
RMX 1500.
You are required to register all Polycom Software Licenses that you have purchased when
retrieving the Activation Key. For example, ISDN, Encryption and Network Separation each have
different Polycom Software Licenses.
On the RMX 1500 MPMx-Q assembly, the use of HD with Continuous Presence requires an
additional licence.
The parameters in the lan.cfg file are uploaded from the USB key to the RMX's memory
and applied during the power-up sequence.
System power-up sequence may take up to five minutes.
During the First-time Power-up the red ERROR LED on the RMX's front panel remains
ON until both the Management and IP Network Services have been defined.
When the RMX's configuration is completed (including the Management and IP Network
Services), and if there are no System Errors, the green READY LED (on the RMX's front
panel) turns ON.
Remove the USB key. For more information see, the RealPresence® Collaboration Server
1500/2000/4000 Getting Started Guide, "Hardware Description", "Procedure 4: Modifying the
Default IP Service and ISDN/PSTN Network Service Settings" on page 2-31.
LAN 2: media,
MNG: signaling,
MNGB: general management
Shelf: shelf management
