RealPresence Collaboration Server (RMX) 1500 LEDs

The RMX includes LEDs located on the front panel and rear panel. In the front panel, the
LEDs reflect the state of the components. The LEDs on the rear panel indicate the state of the
external connections and the status of the RTM IP card.

RealPresence Collaboration Server (RMX) 1500 Front Panel LEDs

The following items appear on the RMX 1500 front panel:
Table 1-9
Component
Front Panel
Polycom, Inc.
RMX 1500 Front Panel LED's
LED ID LED Color
ERROR Red
READY Green
IN USE Amber
Indication
ON - Major system error. In case of an active alarm
this light is ON, and the READY-green is OFF.
OFF - Normal.
Flashes - During system startup.
ON - CPU card has successfully completed startup.
This light initially flashes and then turns on green after
completing the entire system configuration.
OFF - Turns OFF when the ERROR red LED is
activated.
Flashes - During system startup.
ON - At least one endpoint is connected to the
system.
Flashes - During system startup.
Chapter 1-Hardware Description
1-19
