Chapter 5
command is most effective when used in conjunction with the Tag/Tear and
Peel-n-Dispense modes. The "^A1" enables the Infinity Print while a "^A0" will
disable this function.
XX 75 Load Label Count: Instructs the printer to print a batch of labels using the
serial number function if enabled. If the serial number function is disabled, the
^D75 command will print the number of copies (the same label) specified by
the "^Axx" sequence just like the ^D73 command. This command may also be
used in conjunction with the ^D73 command. The batch of labels is printed
once a ^D3 command is executed; therefore the ^D75 command must be
issued before the ^D3 command. The only difference between this command
and the ^D73 is the ability to increment and/or decrement sequential numbers
in a batch.
XXX 76 Load Delay Time Between Printed Labels: Delays the printing between
labels in a batch. The "^Axxx" specifies the delay time in tenths of a second
with a maximum value of 650. For example, "^A10^D76<CR>" would
introduce a one second delay between printed labels. This command is
typically used in conjunction with the Peel-n-Dispense mode and applicators.
5.7

Label Header Parameter Override Commands

It is possible to override label header parameters by adding one or more of the following
commands after the ^D2 and before the print command.
^A ^D COMMAND
40 Clears Commands 41 through 51
XX 41 Load Number of Fields in Layout (HFM): The ^Axx specifies the value.
XX 42 Load Label Width in dots (LSX): The ^Axx specifies the value.
XX 43 Load Label Height in dots (LSY): The ^Axx specifies the value.
XX 44 Load the Web Size in dots (WEB): The ^Axx specifies the value.
XX 45 Load the Gap Size in dots (GAP): The ^Axx specifies the value.
XX 46 Load Print Speed: The ^Axx specifies the value.
XX 47 Load the Label Control Byte (LCB): The ^Axx specifies the value.
XX 48 Load the Number of Steps to Activate Gap Detector (AGD): The ^Axx
specifies the value in Dot Rows.
XX 49 Load the Number of Steps Past Gap (SPG): The ^Axx specifies the value
in Dot Rows.
XX 50 Load X Direction Offset (OFX): The ^Axx specifies the value.
XX 51 Load Y Direction Offset (OFY): The ^Axx specifies the value.
324M/424M Operator's Manual - 880026-0144
Printer Commands
5-35
