Getting Started
3.2.1

Printer Power

Microcom Corporation offers three (3) different "Desktop" universal power supplies as
options. Any power supply that conforms to the standard supply specifications listed in
Table 3-1 below may be used. The printer requires a universal +24VDC power supply that
operates in the 100-240 VAC; 50-60 Hertz range; 4 Amps. The power supply should
operate in an "output fold-back mode" during an overload situation rather than a shutdown
and restart attempt; sometimes referred to as a "Hiccup" mode. Contact your Microcom
Corporation representative for any questions regarding power adapter requirements and/or
specifications.
AC Input:
DC Output:
Power Rating:
Overload Protection:
Maximum Transient Load:
Printer Power Connector:
Table 3-1
AC Input:
DC Output:
Power Rating:
Overload Protection:
Maximum Transient Load:
Printer Power Connector:
Table 3-2
AC Input:
DC Output:
Power Rating:
Overload Protection:
Maximum Transient Load:
Printer Power Connector:
Table 3-3
3-2
100-240 VAC, 50/60 HZ, 4A
+24V @ 0.2 ~4.16A +/- 5%
100 Watts, no cooling, 40
Output Voltage Foldback Mode
12 cycles @ 2.1ms rep. rate;
35A, 650µs pulse
Standard 4-pin power mini-DIN
100 Watt Power Supply, w/o Fan 40
100-240 VAC, 50/60 HZ, 4A
+24V @ 0.2 ~6.25A +/- 5%
150 Watts, internal fan cooling, 60
Output Voltage Foldback Mode
12 cycles @ 2.1 ms rep. rate;
35A, 650 µs pulse
Standard 4-pin power mini-DIN
150 Watt Power Supply, with Fan 60
100-240 VAC, 50/60HZ, 4A
+24V @ 0.2 ~4.16A +/- 5%
85 Watts, no cooling, 40
Output Voltage Foldback Mode
12 cycles @ 2.1ms rep. rate;
35A, 650µs pulse
Standard 4-pin power mini-DIN
85 Watt Power Supply, w/o Fan 70
324M/424M Operator's Manual - 880026-0144
Chapter 3
°
