Settings: Lets you change several operating parameters for the SEL viewer. This menu
displays the following suboptions:
Display HEX/Verbose: Toggles between HEX mode and interpreted mode of displaying
SEL records.
Output Text/Binary: Specifies whether SEL data will be saved to the file in binary
format or verbose format.
Window: Gives options for displaying currently open windows.
Help: Provides version information for the SEL viewer and provides help topics on the
EMP console.
Sensor Data Record (SDR) Viewer
The SDR viewer lets you view the records retrieved from the SDR repository. Options available
through the SDR viewer are:
View all SDR records
View SDR entries by SDR type
View SDR summary information
Set SDR display mode to either Hex or verbose mode
Close the SDR viewer
Exit the EMP console
SDR Viewer Menu Options
The SDR viewer menu bar contains the following:
File
Close: Closes the SDR viewer.
Exit: Exits the EMP console.
View
Display all Records: Displays all records from the SDR repository.
SDR Type: Displays the records of a particular SDR type. You select an SDR type from
a pop-up menu that displays all the SDR types available for the given hardware.
SDR Info: Displays the SDR summary information.
Settings: Lets you change operating parameters for the SDR viewer. This menu displays the
following suboption:
Display HEX/Verbose: Toggles between HEX mode and interpreted mode of displaying
SDR records.
Window: Gives options for displaying currently open windows.
Help: Provides version information for the SDR viewer and provides help topics on the EMP
console.
Field Replaceable Unit Viewer
The FRU viewer lets you view data from the server's baseboard FRU information area. Options
available with the FRU viewer are:
View all FRU records
View FRU summary information
