Sensor Data Record Manager Add-In - Intergraph InterServe 9000 System Reference Manual

Sensor Data Record Manager Add-In

In this window, you can:
Examine all SDR records through the BMC (in either Hex or Verbose mode)
Examine SDR records by Record type (in either Hex or Verbose mode)
Examine SDR records from a previously stored binary file (in either Hex or Verbose mode)
Save the SDR records to a file (in either text or binary form)
The SDR Manager can display SDR records in either raw form (hexadecimal) or in an interpreted,
easy-to-understand textual form (verbose).
The SDR Manager's main window provides access to features of the add-in through menus. Each
option included on the main menu supports an accelerator key. Accelerator keys are indicated by
an underlined letter in the text listing the option.
Figure 10 shows the SDR Manager main window. Table 25 lists the window's menus and options.
52
Figure 10. SDR Manager Main Window
