Cancel: Exits the dialog with no action taken.
Help: Displays dialog-level help information.

Management Plug-ins

System Event Log Viewer
The SEL viewer can display records in either hexadecimal or text (verbose) form. These options
are available through the SEL viewer:
View the SEL from a file
Save the SEL to a file
View SEL summary information
View all SEL entries
View SEL information by event type
View SEL information by sensor type
Set SEL display mode to either Hex or verbose mode
Set the SEL output file format to either text or binary format
Close the SEL viewer
Exit the EMP console
SEL Viewer Menu Options
The following menu options are available on the SEL viewer menu bar:
File
Open: Allows you to view SEL data from a previously saved file if it was stored in binary
format. Selecting the Open Menu item lets you specify a filename under which the data
are found. The default filename is "SELLOG.DAT." If the file cannot be opened, the
program displays an error message.
Close: Closes the SEL viewer.
Save As: Dumps the SEL data to a file in either binary raw or verbose text format. The
binary file can be retrieved later. Selecting this option lets you specify a filename to which
the data can be saved. The default filename is "SELLOG.DAT." If no data exist, an error
message displays.
Exit: Exits the EMP console.
Connect
View
SEL Information: Displays SEL summary information.
All Events: Displays all events in the SEL.
By Sensor Type: Displays all events in the SEL generated by a specific sensor type, for
example, voltage, temperature, etc.
By Event: Displays all events in the SEL of a particular type, for example, by memory or
threshold. A pop-up menu lets you select the event type to display. This menu displays all
event types that can be generated by the particular hardware.
