The SEL viewer's main window provides access to features of the add-in. Each option included on
the main menu supports an accelerator key. Accelerator keys are indicated by an underlined letter
in the text listing the option. The main window i ncludes support to display the following
information for each SEL entry: record identifier, event type, time stamp information, generator
identifier, emv revision, sensor type, sensor number, and event description.
Figure 9 shows the SEL viewer main window. Table 24 lists the window's menus and options.
Table 24.
SEL Viewer Menus
Menu
Options
File
Open SEL: Views data from previously saved SEL file
Save SEL: Saves the currently loaded SEL data to a file
Clear SEL: Clears the SEL data from the BMC
Exit: Quits the SEL Viewer
View
SEL Info: Displays information about the SEL (display only)
All Events: Displays the current SEL data from the BMC
By Sensor: Displays a pop-up menu allowing you to view the data from a certain sensor type
By Event: Displays a pop-up menu allowing you to view the data from a certain event type
Settings
Display Hex/Verbose: Toggles between Hex/interpreted mode of displaying the SEL records
Output Text/Binary: Determines whether SEL data will be saved to the file (and under File -
Save) in binary format or verbose format
Help
About: Displays the SEL Viewer version information
Figure 9. SEL Viewer Add-in Main Window
51
