SMM Connector

2
1
OM08032
Table 38.
Server Management Module Connector Pinout
Pin
Signal
1
CPU_SMI_L
2
LOCAL_I2C_SCL
3
GND
4
Reserved
5
PWR_CNTRL_SFC_L
6
LOCAL_I2C_SDA
7
5VSTNDBY
8
KEYLOCK_SFC_L
9
CPU_NMI
10
VCC3
11
RST_SFC_L
12
GND
13
GND
14
Reserved
15
SECURE_MODE_BMC
16
GND
17
SFC_CHASSIS_INSTRUSION_L
18
Reserved
19
Reserved
20
GND
21
Reserved
22
Reserved
23
Reserved
24
Reserved
25
Key pin (N/C)
26
Reserved
134
26
23
Description
System Management Interrupt
IPMB clock line
Ground
N/A
Host power supply on/off control
IPMB serial data line
+5V standby indication (power OK)
Keyboard lock signal
Nonmaskable interrupt indication
3.3V power supply status input
Baseboard reset signal from Server Monitor Module
Ground
Ground
N/A
Secure mode indication
Ground
Chassis intrusion indication
N/A
N/A
Ground
N/A
N/A
Not used
N/A
Connector key
N/A
