8. Click the Add Drive button to register your new logical drive.
9. Click Apply to save the configuration if you are finished setting up
logical drives, OR
Repeat the process above to set up additional logical drives, then click
Apply when you're done.
An example of a completed Manual configuration is shown in Figure 4-25:
Figure 4-25. Sample Manual Configuration Just Before "Apply"
Note
In Manual Configuration, Add Logical Drive and
Expand Array function very similarly to what was
shown above. In each of these two cases, however,
RAID Assist shows you the disk arrays and logical
drives and allows you to add to the configuration
without risking existing data.
