Enclosure Monitoring and Management
• Absent – The alarm is not installed, or has failed in an undetectable
way.
• OK – The alarm is optimal. One additional item is displayed with
this state: ON – the alarm is currently on or sounding.
• Failed – The alarm is installed, but has failed.
The status of the enclosure's connection to one or more Uninterruptable
Power Supplies (UPS). Each UPS is designated with a number. The status
values are:
• Absent – The UPS is not installed, or has failed in an undetectable
way.
• OK – The UPS is optimal. Three additional items are displayed with
this state: AC Pwr – the UPS is reporting an AC power failure; DC
Pwr – the UPS is reporting a DC power failure; Low Bat – the UPS
can power the system for only 2 to 5 more minutes.
• Failed – The UPS is installed, but has failed.
Error status for troubleshooting purposes. Error status for an enclosure is
reported in a format similar to the following example:
0 Addressing 25 02:03 04:05
• 0 is the error number.
• Addressing is the error type.
• 25 is the ALPA (Arbitrated Loop/Port Address) of the drive in
question.
• 02:03 is the first known channel and target to which the ALPA is
mapped.
• 04:05 is the second known channel and target to which the ALPA is
mapped.
An information field which contains most of the items listed on the
Information page for easier cross-reference.
Highlight an enclosure and the Locate button will become available. Click
the Locate button to "blink" the LEDs of all of the physical drives in the
enclosure to reveal its location. A locate enclosure dialog box will open,
click OK or press the Enter key to end the locate operation and return to
normal status.
