• Consistency Check Status: Displays the progress (percent complete)
of an ongoing logical drive consistency check.
• Expand Capacity Status: Displays the progress (percent complete) of
an ongoing data restriping process across the target RAID group.
• Patrol Read Status: Enables GAM Client to poll every 1 minute to get
new status data from the controller.
• Error Table: Displays a table of bad block and "request sense" data
generated as a result of finding areas of damage or data unavailability
on a storage device. Data for all storage devices on the selected
controller are presented in the same tables.
• Cluster Map: Displays a graphical back end cable connection for the
controller selected from the cluster controller list.

Administration Menu

The Administration menu (Figure 3-8) contains the following options:
• Sign On: Enables use of GAM's configuration and administration
functions to "Administrators" ("gamroot" + password). Enables only
monitoring functions to "Users."
• Define Server Groups: Sets up server groups and individual server
names or IP addresses within each group.
• Select Current Server Group (Ctrl+G): Displays the current contents
of the server selection box located in the Global Array Manager
window. Functions in the same way as directly selecting the server
selection box.
• Select Current Controller (Ctrl+C): Displays the current contents of
the controller selection box located in the Global Array Manager
window. Functions in the same way as directly selecting the controller
selection box.
• RAID Assist: Mylex's built-in RAID Controller configuration utility.
Facilitates configuration tasks using either one-step "automatic"
configuration, a configuration "wizard" assistant, or a manual
(advanced level) configuration option allowing more control over
configuration parameters.
